OUTBACK |
| |
MIN WEIGHT |
MAX WEIGHT |
| Vne Knots (IAS) |
54 (62 mph) |
54 (62 mph) |
| Manoeuvring speed Knots (IAS) |
54 (62 mph) |
54 (62 mph) |
| Trim Speed (middle hole) Knts (IAS) |
30-36 (35-41 mph) |
30-36 (35-41 mph) |
| Stall Speed Power Off knots (IAS) |
23 (27 mph) |
28 (33 mph) |
| Take Off Safety Speed knots (IAS) |
31 (36 mph) |
37 (43 mph) |
| Nominated approach speed knots (IAS) |
31 (35 mph) |
37 (43 mph) |
| Maximum Level Speed knots (IAS) |
50 (57 mph) |
50 (57 mph) |
| Cross winds of up to knots |
11 (12 mph) |
14 (16 mph) |
| Climb Rate at take off safety speed
fpm |
|
430 |
| Cruising Speed Fwd CG knots (IAS) |
40 (46 mph) |
45 (52 mph) |
| Sink Rate at cruising speed fpm |
|
450 |
| Sink Rate at Vne fpm |
|
904 |
| Glide Ratio (engine off) |
10:1 |
10:1 |
| Take Off Distance (See Note 1) |
240 metres (787 feet) |
|
| Landing Distance (See Note 1) |
210 metres (689 feet) |
|
| Min airstrip length metres |
310 metres (1017 feet) |
|
| Max wind operating conditions (at ground
Level) knots |
20 (23 mph) |
20 (23 mph) |
| Rigging time |
Base 5 minutes |
Wing 15 minutes |
| Wing weight |
45 kgs (99 lbs) |
|
| Trike empty weight from |
118 kg (260 lbs) |
|
| Aircraft total empty weight from |
|
165 kg (363.7 lbs)(see note 1) |
| Max. take off weight |
401 kg (884 lbs) |
|
| Wing span |
|
9.96 metres |
| Wing area |
|
17.6 sq metres |
| Aspect ratio |
|
5.6:1 |
| Nose angle |
|
121 degrees |
| No. of seats |
2 |
|
| Fuel tank capacity |
44 litre (11.62 gallons) |
|
|
|
|
|
