M3 Sport Specifications

XT-912 SPECIFICATIONS
PERFORMANCE   XR-S
Never Exceed Speed (Vne) indicated kts 85
  mph 98
  km/h 157
Manoeuvring Speed (Va) indicated kts 80
Never exceed in turbulent air mph 92
  km/h 148
Cruise Speed @ MTOW kts 70
  mph 81
  km/h 130
Trim Speed  kts 60-65
  mph 69-75
  km/h 111-120
Stall Speed @ 450kg (MTOW) kts 35
  mph 40
  km/h 65
Stall Speed @ 320kg kts 31
  mph 36
  km/h 57
Climb Rate @ MTOW 450kg ft/m 925
at recommended climb speed m/s 4.7
Recommended Climb Speed kts 49
Take Off Safety Speed mph 56
  km/h 91
Take off Run ft 344
Measure from short grass run way m 105
Take off Distance to 15 mts or 50 feet- Note 1 ft 771
Measure from short grass run way m 235
Maximum Cross Wind kts 15
Max gust factor of 5-10 kts.   mph 17
  km/h 28
Land Distance @ MTOW from 15 mts- Note 1 ft 1050
Measure from short grass run way m 320
Descent Rate 49 kts @ MTOW  ft/m 650
  m/s 3.3
Glide Angle at 49 kts @ MTOW angle 7.18
Glide Distance from 1000 ft miles 1.4
  km 2.2
Typical Fuel Burn @ Cruise (MTOW) L/hr 10.5
  US Gal/hr 2.8
Range @  Cruise miles 459
Max useable fuel 56 litres (17.7US Gallon) km 739

DESIGN LOADS   XR-S
Max take off weight (MTOW / W Max) kg 450
  pound 992
Wing Weight kg 57
  pound 126
Max Base Weight (W susp) kg 393
  pound 866
Typical Empty Weight kg 241
Standard XT3 Base (no options) 184kg pound 531
Useable Load kg 209
Optional Equipment Excluded pound 461
Pilot weight range (Front Seat) kg 55-115
(Max total load 215kg - 482lb) pound 224-258
Pilot weight range (Rear Seat) kg 0-115
(Max total load 215kg - 482lb) pound 0-258
DIMENSIONS (Tundra base)   XR-S
Wing Span m 9.5
  ft 31.0
Wing Area sq m 12.9
  sq ft 139
Aspect Ratio   6.9
Wing Weight kg 57.0
  pound 126
Overall Height (Control bar forward) m 3.1
  ft 10.1
Trike Width (To outside of wheels) m 1.9
  ft 6.3
Trike Length m 2.8
  ft 9.0
Wheel Track m 1.7
  ft 5.6
Wheel Base m 1.9
  ft 6.2
Trike Height (Mast Folded Down) m 1.7
  ft 5.6
Cockpit Width m 0.76
  ft 2.5
Wing (Packed) Length m 5.3
  ft 17.4
Wing Length (Short Packed) m 4.0
  ft 13.1
POWER PLANT
Make Rotax
Model 912 UL
Power 80 Hp
Type 4 Stroke-1211cc
Ignition System Dual Electronic
No Cylinders 4
Electric Start Standard
Reduction Ratio 2.43:1

Fuel Limitations
Maximum Usable Fuel  Litre 56
  UK Gal 12.3
  US Gal 14.8
