REV Specifications
|
REV
13.5 and REV 14.5
|
|
|
REV 13.5
|
REV 14.5
|
| |
Metric |
Imperial |
Metric |
Imperial |
|
Sail Area
|
13.43 sq m
|
144 sq ft
|
14.45 sq m
|
156 sq ft
|
|
Wing span
|
10.04 m
|
32.9 feet
|
10.64 m
|
34.9 ft
|
|
Aspect ratio
|
7.5
|
7.8 |
|
Nose angle
|
126-131 degrees
|
126-131 degrees |
|
Double surface %
|
95%
|
95% |
|
Battens
|
24 + 6
|
24 + 6 |
|
Glider weight
|
33 kg
|
72 lbs
|
35 kg
|
77 lbs
|
|
Pack up length
|
5.0 m
|
16.4 ft
|
5.3 m
|
17.4 ft
|
|
Short pack length
|
3.9 m
|
12.8 ft
|
4.2 m
|
13.77 ft
|
|
Recommended pilot hook in weight
range (inc equipment)
|
70-105 kg
|
154-231 Ibs
|
85-120 kg
|
187-264 lbs
|
|
VNE (Recommended Velocity
to Never Exceed)
|
90 km/h
|
55 mph
|
90 km/h
|
55 mph
|
VA (Recommended Max.
Rough Air Manoeuring Velocity) |
74 km/h
|
46 mph |
74 km/h
|
46 mph |
| VD (Maximum Steady
State Velocity) |
125 km/h
|
78 mph |
125 km/h
|
78 mph |
Table 2 Specifications Note: The stall speed of the Rev at
maximum recommended wing loading is less than the minimum
requirement of 25 mph (40 km/h).
Conversions: * 0.4536 kg/pound * 25.4 mm/inch * 1.609 km/mile
Va = Test speed x 0.707
Vne = Test Speed x 0.816
|
